Fluke 115 - Field Technician’s Digital Multimeter
UPC: 095969324182 | Model: Fluke 115
Fluke 115
Compare
TRUE-RMS AC/DC DIGITAL MULTIMETER
- Compact meter for a wide variety of electrical/electronic testing applications
- True RMS
- Measures AC/DC voltage and current, resistance, capacitance, diode testing, frequency and more
- 3.5 digits / 6000 counts
- Measure up to 600V / 10A AC/DC (20A overload for 30-seconds max)
- Backlight for use in dimly lit areas
- Min/Max/Average to record signal fluctuations
- Easy, one-handed operation
- Compatible with Fluke TPAK magnetic meter hanging kit (sold separately)
- CAT III 600V safety rating
Description
Fluke 115 Field Technician’s Digital Multimeter
The Fluke 115 field technician’s digital multimeter measures True-RMS voltage and current, as well as resistance, continuity, frequency, and capacitance, to meet the needs of a wide variety of field service technicians.
The 115 digital multimeter is easy to use and offers simple, one-handed operation. Its backlit display provides large, easy-to-read digits with a 6000-count resolution. The 115 provides Min/Max/Average with elapsed time to record signal fluctuations.
Manufacturer Specifications
| Maximum voltage between any terminal and earth ground | 600 V |
|---|---|
| Surge protection | 6 kV peak per IEC 61010-1 600 V CAT III, Pollution Degree 2 |
| Display | Digital: 6,000 counts, updates 4/sec |
| Bar graph | 33 segments, updates 32/sec |
| Operating temperature | -10 °C to +50 °C |
| Storage temperature | -40 °C to +60 °C |
| Battery | 9V Alkaline, NEDA 1604A/IEC 6LR61 |
| Battery life | 400 hours typical, without backlight |
| Measurement Accuracy | |
| DC millivolts | Range: 600.0 mV / Resolution: 0.1 mV / Accuracy: 2.0% + 3 |
| DC volts | 6.000 V (0.001 V), 60.00 V (0.01 V), 600.0 V (0.1 V) |
| Auto volts | 600.0 V / 0.1 V / 2.0% + 3 (dc, 45 Hz–500 Hz), 4.0% + 3 (500 Hz–1 kHz) |
| AC millivolts (True-RMS) | 600.0 mV / 0.1 mV / 1.0% + 3 (45 Hz–500 Hz), 2.0% + 3 (500 Hz–1 kHz) |
| AC volts (True-RMS) | 6.000 V (0.001 V), 60.00 V (0.01 V), 600.0 V (0.1 V) |
| Continuity | 600 Ω / 1 Ω / Beeper on < 20 Ω, off > 250 Ω; detects opens/shorts ≥ 500 µs |
| Ohms | 600.0 Ω (0.1 Ω), 6.000 kΩ (0.001 kΩ), 60.00 kΩ (0.01 kΩ), 600.0 kΩ (0.1 kΩ), 6.000 MΩ (0.001 MΩ), 40.00 MΩ (0.01 MΩ) |
| Diode test | 2.000 V / 0.001 V / 0.9% + 2 |
| Capacitance | 1000 nF (1 nF), 10.00 µF (0.01 µF), 100.0 µF (0.1 µF), 9999 µF (1 µF) |
| AC amps (True-RMS) | 6.000 A (0.001 A), 10.00 A (0.01 A) / Accuracy: 1.5% + 3 |
| DC amps | 6.000 A (0.001 A), 10.00 A (0.01 A) / Accuracy: 1.0% + 3 |
| Frequency (V or A input) | 99.99 Hz (0.01 Hz), 999.9 Hz (0.1 Hz), 9.999 kHz (0.001 kHz), 50.00 kHz (0.01 kHz) / Accuracy: 0.1% + 2 |
Tech Specs
| Multimeters Template | |
|---|---|
| Style | Hand-Held |
| Measures AC V | Yes |
| Measures DC V | Yes |
| Measures AC A | Yes |
| Measures DC A | Yes |
| True RMS | Yes |
| Maximum Voltage AC | 600 V |
| Resolution AC Volts | 0.1 mV |
| Maximum Voltage DC | 600 V |
| Resolution DC Volts | 0.1 mV |
| Maximum Current AC | 10.0 A |
| Minimum Current AC | 0.001 A (1 mA) |
| Resolution AC Current | 0.001 A (1 mA) |
| Maximum Current DC | 10.00 A |
| Minimum Current DC | 0.001 A (1 mA) |
| Resolution DC Current | 0.001 A (1 mA) |
| Basic Accuracy V DC | 2% |
| # Digit Display | 3.5 |
| Counts | 6000 |
| Backlight | Yes |
| Manual/Autoranging | Both |
| Decibels | No |
| Resistance | Yes |
| Frequency | Yes |
| Capacitance | Yes |
| Temperature | No |
| Diode Testing | Yes |
| CAT Rating | III |
| CAT Voltage | 600 V |
| Intrinsically Safe | No |
| Peak Hold | No |
| Overload Protector | Yes |
| Kelvin 4-Wire Measurement Capability | No |
| Wireless Display | No |
| Data Hold | Yes |
| Low-Pass Filter | No |
Test Equipment General Attributes
| Unique Features | Large white LED backlight for poorly lit areas; frequency and capacitance; 10A ac/dc current measurement (20 A overload for 30 seconds max); Min/Max/Average to record signal fluctuations. |
|---|---|
| Warranty | 3 YEARS |
| Safety Approval | CSA, UL |
| Interfaces I/O | Analog Output, Analog Input |
| IP Rating | IP42 |
| Product Weight | 1.34 LBS |
| Product Height | 1.82 IN |
| Product Length | 6.57 IN |
| Product Width | 3.31 IN |
| Data Logging | No |
| ECCN Number | 3A992 |
| Calibration Included | Factory Calibration |
| Battery Type | 9V |
| Power Supply Voltage | Battery Powered |
| Country of Origin | Singapore |
| UPC | 095969324182 |
