Fluke 1587 FC - Insulation Tester / Multimeter

Catalog: 4691215  |  UPC: 095969796620  |  Model: Fluke 1587 FC

Fluke 1587 FC

Compare

Fluke 1587 FC True-RMS Megohmmeter / Insulation Resistance Tester and Multimeter with Fluke Connect Compatibility

  • 2-in-1 instrument: insulation tester and digital multimeter
  • Insulation test range: 0.01 MΩ to 2 GΩ
  • Insulation test voltages: 50 V, 100 V, 250 V, 500 V, 1000 V
  • PI/DAR timed ratio tests with TrendIt graphs (via Fluke Connect)
  • Compatible with free Fluke Connect app for remote monitoring and storage
  • VFD low-pass filter for accurate motor drive measurements
  • Live circuit detection prevents test if voltage > 30 V
  • Measures AC/DC voltage, DC millivolts, AC/DC milliamps, resistance, continuity
  • Additional functions: capacitance, diode test, temperature, frequency, Min/Max
  • CAT III 1000 V, CAT IV 600 V safety rating
  • Auto-discharge of capacitive voltage for user safety
  • 3-year warranty

Description

The Fluke 1587 FC Insulation Multimeter combines a true-RMS digital multimeter with an insulation resistance tester in one compact tool. With multiple test voltages, advanced PI/DAR testing, VFD low-pass filter, and Fluke Connect compatibility, it’s designed for versatile troubleshooting, commissioning, and preventative maintenance.

Using the Fluke Connect app, technicians can perform timed ratio tests, trend graphs, track historical data, and share results wirelessly, eliminating errors and saving time. The rugged handheld design and extensive measurement capabilities make the 1587 FC an essential tool for industrial, commercial, and utility electricians.

Applications: Motor drive testing, predictive maintenance, troubleshooting insulation failures, electrical safety inspections, and historical tracking with Fluke Connect.

Manufacturer Specifications

Insulation Testing
Measurement Range 0.01 MΩ to 2 GΩ
Test Voltages 50 V, 100 V, 250 V, 500 V, 1000 V
Test Voltage Accuracy +20 %, -0 %
Short Circuit Current 1 mA nominal
Live Circuit Detection Inhibits test if terminal voltage > 30 V
Auto Discharge < 0.5 seconds for ≤ 1 µF load
Electrical Measurements
AC Voltage Up to 1000 V (True RMS, ±1–2%)
DC Voltage Up to 1000 V (±0.09 % + 2)
AC/DC Current Up to 400 mA
Resistance 0.1 Ω to 50 MΩ
Capacitance Up to 9999 µF
Frequency Up to 100 kHz
Temperature -40 °C to 537 °C (K-type thermocouple)
Diode Test Yes
Continuity Audible tone below 25 Ω
General Specifications
Safety Ratings CAT IV 600 V, CAT III 1000 V
IP Rating IP40
Battery Type 4 × AA alkaline
Battery Life 1000 hours (meter use) / 1000 insulation tests
Operating Temperature -20 °C to 55 °C
Storage Temperature -40 °C to 60 °C
Relative Humidity 0–95 % (≤ 30 °C), 0–40 % (up to 55 °C)
Dimensions 5.0 × 10.0 × 20.3 cm (1.97 × 3.94 × 8.00 in)
Weight 550 g (1.2 lbs)
Altitude Operating: 2000 m; Storage: 12,000 m
Warranty 3 years

Tech Specs

Multimeters Template
Style Handheld
True RMS Yes
AC/DC Voltage Up to 1000 V
AC/DC Current Up to 400 mA
Resistance Yes
Frequency Yes
Capacitance Yes
Temperature Yes
Diode Testing Yes
Display 3.75 digit, 6000 counts, backlit
Manual/Autoranging Both
Low-Pass Filter Yes (VFD measurements)
Data Hold Yes
Peak Hold Yes
CAT Rating CAT IV
CAT Voltage 600 V (CAT IV), 1000 V (CAT III)
Megohmmeter Template
IR Test Voltage 50 V, 100 V, 250 V, 500 V, 1000 V
Max Insulation Resistance 2 GΩ
Min Insulation Resistance 0.01 MΩ
Continuity Test Yes
Live Circuit Voltage Detection Yes (> 30 V)

Test Equipment General Attributes

Unique Features Combines insulation tester and multimeter; Fluke Connect compatible; PI/DAR tests with TrendIt graphs; Low-pass filter for VFD; Insulation smoothing reading; Historical data tracking via app
Warranty 3 Years
Safety Approval CSA
IP Rating IP40
Product Weight 4.72 lbs
Product Height 7.99 in
Product Length 3.97 in
Product Width 7.96 in
Data Logging No
Calibration Included None
Battery Type AA
Power Supply Battery Powered
Country of Origin United States
UPC 095969796620
