Fluke 190-202-III-S - Color ScopeMeter, 200MHz, 2 Channel with Software Package
Rating: 0 Reviews | Catalog: 5282442 | UPC: 195112021859 | Model: Fluke 190-202-III-S
Fluke 190-202 - ScopeMeter III Series
Compare
FLUKE-190-202-III-S, ScopeMeter 2 Channel 200MHz Color SCC
- FlukeView 2 ScopeMeter software for documenting, archiving and analysis
- Number of channels: 2
- Bandwidth: 200 MHz
- Rise time: 1.7 ns
- Number of scope inputs: 2 input channels plus external trigger
- Sampling rate: 2.5 GS/s (each channel)
- CAT III 1000 V / CAT IV 600 V safety rated instrument for industrial environments
- Large, bright color display is easy to view in nearly any environment
- Deep memory: 10,000 points per trace waveform capture (scope mode)
- Connect-and-View triggering - intelligent, automatic triggering on fast, slow, or complex signals
Description
Fluke 190-202-III-S - Color ScopeMeter, 200MHz, 2 Channel with Software Package
The Fluke 190-202-III-S ScopeMeter is designed for industrial environments, combining ruggedness, portability, and advanced oscilloscope functionality. With a bandwidth of 200 MHz, 2 input channels, and sampling rates up to 2.5 GS/s, it provides accurate, reliable waveform capture and analysis.
FlukeView 2 software allows users to document, archive, and analyze measurements. The ScopeMeter’s CAT III 1000 V / CAT IV 600 V safety rating ensures use in demanding applications, while its large color display and deep memory (10,000 points) make it suitable for both quick troubleshooting and detailed analysis.
Tech Specs
Oscilloscopes / Portable Oscilloscopes
| Bandwidth | 200 MHz |
|---|---|
| Channels | 2 |
| Sampling Rate | 2.5 GS/s (2500 MS/s) |
| Screen Type | LCD |
| Isolated Inputs | Yes |
| Screen Size | 5.3 in |
| Color Screen | Yes |
| Rise Time | 1.7 ns |
| Memory | 10,000 Points (0.00098 kB) |
Test Equipment General Attributes
| Product Weight | 4.6 lbs |
|---|---|
| Shipping Weight | 5.29 lbs |
| HTS/Schedule B Number | 9030.20.1000 |
| ECCN Number | 3A992.G |
| Country of Origin | Romania |
Fluke 190-202-III-S - Color ScopeMeter, 200MHz, 2 Channel with Software Package
Rating: 0 Reviews | Catalog: 5282442 | UPC: 195112021859 | Model: Fluke 190-202-III-S
Fluke 190-202 - ScopeMeter III Series
Compare
FLUKE-190-202-III-S, ScopeMeter 2 Channel 200MHz Color SCC
- FlukeView 2 ScopeMeter software for documenting, archiving and analysis
- Number of channels: 2
- Bandwidth: 200 MHz
- Rise time: 1.7 ns
- Number of scope inputs: 2 input channels plus external trigger
- Sampling rate: 2.5 GS/s (each channel)
- CAT III 1000 V / CAT IV 600 V safety rated instrument for industrial environments
- Large, bright color display is easy to view in nearly any environment
- Deep memory: 10,000 points per trace waveform capture (scope mode)
- Connect-and-View triggering - intelligent, automatic triggering on fast, slow, or complex signals
Description
Fluke 190-202-III-S - Color ScopeMeter, 200MHz, 2 Channel with Software Package
The Fluke 190-202-III-S ScopeMeter is designed for industrial environments, combining ruggedness, portability, and advanced oscilloscope functionality. With a bandwidth of 200 MHz, 2 input channels, and sampling rates up to 2.5 GS/s, it provides accurate, reliable waveform capture and analysis.
FlukeView 2 software allows users to document, archive, and analyze measurements. The ScopeMeter’s CAT III 1000 V / CAT IV 600 V safety rating ensures use in demanding applications, while its large color display and deep memory (10,000 points) make it suitable for both quick troubleshooting and detailed analysis.
Tech Specs
Oscilloscopes / Portable Oscilloscopes
| Bandwidth | 200 MHz |
|---|---|
| Channels | 2 |
| Sampling Rate | 2.5 GS/s (2500 MS/s) |
| Screen Type | LCD |
| Isolated Inputs | Yes |
| Screen Size | 5.3 in |
| Color Screen | Yes |
| Rise Time | 1.7 ns |
| Memory | 10,000 Points (0.00098 kB) |
Test Equipment General Attributes
| Product Weight | 4.6 lbs |
|---|---|
| Shipping Weight | 5.29 lbs |
| HTS/Schedule B Number | 9030.20.1000 |
| ECCN Number | 3A992.G |
| Country of Origin | Romania |
