Fluke 87-5 Industrial Multimeter (87-V)
INDUSTRIAL TRUE RMS MULTIMETER
- True RMS, heavy-duty industrial multimeter
- Provides the resolution and accuracy to efficiently troubleshoot motor drives, plant automation, power distribution, and more
- Supports accurate measurements on VFDs using a low-pass filter
- Captures intermittent signals as fast as 250µs using Peak Capture
- Special shielding blocks high-frequency, high-energy noise from large drive systems
- Frequency to 200 kHz and % duty cycle
- 10,000 µF capacitance range for components and motor caps
- Designed to withstand spikes of more than 8000 V
- CAT III 1000 V, CAT IV 600 V safety rated
- 400-hour battery life (with backlight off)
Description
Fluke 87V – Industrial Multimeter
The Fluke 87V provides resolution and accuracy for troubleshooting motor drives, automation, power distribution, and electromechanical equipment—even in loud, high-energy, or high-altitude environments. Its low-pass filter ensures accurate VFD measurements, while Peak Capture mode records intermittent events as fast as 250 µs.
Features include a large dual-level backlit display, analog bar graph, Touch Hold, and removable holster with built-in probe storage. With True-RMS AC/DC measurement, temperature input, and advanced noise filtering, the 87V helps identify complex electrical issues quickly and accurately.
Built to the highest safety standards (CAT III 1000 V / CAT IV 600 V), the 87V withstands spikes over 8000 V and provides Input Alert warnings if test leads are incorrectly connected. Backed by a lifetime warranty, it’s designed and manufactured in the USA.
Manufacturer Specifications
| DC Voltage | |
|---|---|
| Max Voltage | 1000 V |
| Accuracy | ±(0.1% + 1) |
| Max Resolution | 100 µV |
| AC Voltage | |
| Max Voltage | 1000 V |
| Accuracy | ±(0.5% + 2) |
| Bandwidth | 5 kHz (with LPF, 3 dB @ 1 kHz) |
| Max Resolution | 0.1 mV |
| DC Current | |
| Max Amps | 10 A |
| Accuracy | ±(0.4% + 2) |
| Max Resolution | 0.01 mA |
| AC Current | |
| Max Amps | 10 A |
| Accuracy | ±(1.2% + 2) |
| Max Resolution | 0.1 µA |
| Resistance | |
| Max Resistance | 50 MΩ |
| Accuracy | ±(0.4% + 1) |
| Max Resolution | 0.1 Ω |
| Capacitance | |
| Max Capacitance | 9,999 µF |
| Accuracy | ±(1% + 2) |
| Max Resolution | 0.01 nF |
| Frequency | |
| Max Frequency | 200 kHz |
| Accuracy | ±(0.005% + 1) |
| Max Resolution | 0.01 Hz |
| Duty Cycle | |
| Range | 0.0 to 99.9% |
| Accuracy | ±(0.2%/kHz + 0.1%) |
| Resolution | 0.1% |
| Temperature Measurement | |
| Range (87V) | −200 °C to 1090 °C |
| Range (87V/E) | −328 °F to 1994 °F |
| Probe Range (80BK) | −40 °C to 260 °C / −40 °F to 500 °F |
| Conductance | |
| Max Conductance | 60.00 nS |
| Accuracy | ±(1.0% + 10) |
| Resolution | 0.01 nS |
| Operating Range | |
| Operating Temp | −20 °C to 55 °C |
| Storage Temp | −40 °C to 60 °C |
| Physical | |
| Dimensions | 5.2 × 9.8 × 20.1 cm (2.06 × 3.86 × 7.93 in) |
| Weight | 624 g (22 oz) |
Tech Specs
| Multimeters Template | |
|---|---|
| Style | Hand-Held |
| Measures AC V | Yes |
| Measures DC V | Yes |
| Measures AC A | Yes |
| Measures DC A | Yes |
| True RMS | Yes |
| Max Voltage AC | 1000 V |
| Resolution AC Volts | 0.1 mV |
| Max Voltage DC | 1000 V |
| Resolution DC Volts | 0.1 mV |
| Max Current AC | 10 A |
| Min Current AC | 0.1 µA |
| Resolution AC Current | 0.1 µA |
| Max Current DC | 10 A |
| Min Current DC | 0.1 µA |
| Resolution DC Current | 0.1 µA |
| Basic Accuracy V DC | ±(0.05% + 1) |
| # Digit Display | 4.5 |
| Counts | 6000 (20,000 in high-res mode) |
| Backlight | Yes |
| Manual/Autoranging | Both |
| Resistance | Yes |
| Frequency | Yes |
| Capacitance | Yes |
| Temperature | Yes |
| Diode Testing | Yes |
| CAT Rating | CAT IV 600 V / CAT III 1000 V |
| Peak Hold | Yes |
| Overload Protection | Yes |
| Data Hold | Yes |
| Low-Pass Filter | Yes (for VFD measurements) |
| Duty Cycle % | 0.0 – 99.9% (±0.2%/kHz + 0.1%) |
Test Equipment General Attributes
| Unique Features | Accurate VFD voltage/frequency measurements with selectable low-pass filter. Built-in thermometer. Optional magnetic hanger for hands-free use. Large dual-level backlit display. True-RMS for nonlinear signals. Peak capture (250 µs). Touch Hold. Relative mode. Analog bar graph. Input Alert safety warning. |
|---|---|
| Warranty | 10 years (lifetime on select parts) |
| Safety Approval | CSA, UL |
| Interfaces I/O | Analog input |
| Product Weight | 0.78 lbs |
| Product Height | 1.25 in |
| Product Length | 7.35 in |
| Product Width | 3.41 in |
| Data Logging | No |
| ECCN Number | 3A992 |
| Calibration Included | Factory Calibration |
| Battery Type | 9V |
| Power Supply Voltage | Battery Powered |
| Country of Origin | United States |
| UPC | 095969245241 |
Fluke 87-5 Industrial Multimeter (87-V)
INDUSTRIAL TRUE RMS MULTIMETER
- True RMS, heavy-duty industrial multimeter
- Provides the resolution and accuracy to efficiently troubleshoot motor drives, plant automation, power distribution, and more
- Supports accurate measurements on VFDs using a low-pass filter
- Captures intermittent signals as fast as 250µs using Peak Capture
- Special shielding blocks high-frequency, high-energy noise from large drive systems
- Frequency to 200 kHz and % duty cycle
- 10,000 µF capacitance range for components and motor caps
- Designed to withstand spikes of more than 8000 V
- CAT III 1000 V, CAT IV 600 V safety rated
- 400-hour battery life (with backlight off)
Description
Fluke 87V – Industrial Multimeter
The Fluke 87V provides resolution and accuracy for troubleshooting motor drives, automation, power distribution, and electromechanical equipment—even in loud, high-energy, or high-altitude environments. Its low-pass filter ensures accurate VFD measurements, while Peak Capture mode records intermittent events as fast as 250 µs.
Features include a large dual-level backlit display, analog bar graph, Touch Hold, and removable holster with built-in probe storage. With True-RMS AC/DC measurement, temperature input, and advanced noise filtering, the 87V helps identify complex electrical issues quickly and accurately.
Built to the highest safety standards (CAT III 1000 V / CAT IV 600 V), the 87V withstands spikes over 8000 V and provides Input Alert warnings if test leads are incorrectly connected. Backed by a lifetime warranty, it’s designed and manufactured in the USA.
Manufacturer Specifications
| DC Voltage | |
|---|---|
| Max Voltage | 1000 V |
| Accuracy | ±(0.1% + 1) |
| Max Resolution | 100 µV |
| AC Voltage | |
| Max Voltage | 1000 V |
| Accuracy | ±(0.5% + 2) |
| Bandwidth | 5 kHz (with LPF, 3 dB @ 1 kHz) |
| Max Resolution | 0.1 mV |
| DC Current | |
| Max Amps | 10 A |
| Accuracy | ±(0.4% + 2) |
| Max Resolution | 0.01 mA |
| AC Current | |
| Max Amps | 10 A |
| Accuracy | ±(1.2% + 2) |
| Max Resolution | 0.1 µA |
| Resistance | |
| Max Resistance | 50 MΩ |
| Accuracy | ±(0.4% + 1) |
| Max Resolution | 0.1 Ω |
| Capacitance | |
| Max Capacitance | 9,999 µF |
| Accuracy | ±(1% + 2) |
| Max Resolution | 0.01 nF |
| Frequency | |
| Max Frequency | 200 kHz |
| Accuracy | ±(0.005% + 1) |
| Max Resolution | 0.01 Hz |
| Duty Cycle | |
| Range | 0.0 to 99.9% |
| Accuracy | ±(0.2%/kHz + 0.1%) |
| Resolution | 0.1% |
| Temperature Measurement | |
| Range (87V) | −200 °C to 1090 °C |
| Range (87V/E) | −328 °F to 1994 °F |
| Probe Range (80BK) | −40 °C to 260 °C / −40 °F to 500 °F |
| Conductance | |
| Max Conductance | 60.00 nS |
| Accuracy | ±(1.0% + 10) |
| Resolution | 0.01 nS |
| Operating Range | |
| Operating Temp | −20 °C to 55 °C |
| Storage Temp | −40 °C to 60 °C |
| Physical | |
| Dimensions | 5.2 × 9.8 × 20.1 cm (2.06 × 3.86 × 7.93 in) |
| Weight | 624 g (22 oz) |
Tech Specs
| Multimeters Template | |
|---|---|
| Style | Hand-Held |
| Measures AC V | Yes |
| Measures DC V | Yes |
| Measures AC A | Yes |
| Measures DC A | Yes |
| True RMS | Yes |
| Max Voltage AC | 1000 V |
| Resolution AC Volts | 0.1 mV |
| Max Voltage DC | 1000 V |
| Resolution DC Volts | 0.1 mV |
| Max Current AC | 10 A |
| Min Current AC | 0.1 µA |
| Resolution AC Current | 0.1 µA |
| Max Current DC | 10 A |
| Min Current DC | 0.1 µA |
| Resolution DC Current | 0.1 µA |
| Basic Accuracy V DC | ±(0.05% + 1) |
| # Digit Display | 4.5 |
| Counts | 6000 (20,000 in high-res mode) |
| Backlight | Yes |
| Manual/Autoranging | Both |
| Resistance | Yes |
| Frequency | Yes |
| Capacitance | Yes |
| Temperature | Yes |
| Diode Testing | Yes |
| CAT Rating | CAT IV 600 V / CAT III 1000 V |
| Peak Hold | Yes |
| Overload Protection | Yes |
| Data Hold | Yes |
| Low-Pass Filter | Yes (for VFD measurements) |
| Duty Cycle % | 0.0 – 99.9% (±0.2%/kHz + 0.1%) |
Test Equipment General Attributes
| Unique Features | Accurate VFD voltage/frequency measurements with selectable low-pass filter. Built-in thermometer. Optional magnetic hanger for hands-free use. Large dual-level backlit display. True-RMS for nonlinear signals. Peak capture (250 µs). Touch Hold. Relative mode. Analog bar graph. Input Alert safety warning. |
|---|---|
| Warranty | 10 years (lifetime on select parts) |
| Safety Approval | CSA, UL |
| Interfaces I/O | Analog input |
| Product Weight | 0.78 lbs |
| Product Height | 1.25 in |
| Product Length | 7.35 in |
| Product Width | 3.41 in |
| Data Logging | No |
| ECCN Number | 3A992 |
| Calibration Included | Factory Calibration |
| Battery Type | 9V |
| Power Supply Voltage | Battery Powered |
| Country of Origin | United States |
| UPC | 095969245241 |
