Fluke 88-5 - Deluxe Automotive Multimeter
Catalog: 2550519 | UPC: 095969328906 | Model: Fluke 88-5
Fluke 88-V
Compare
AUTOMOTIVE MULTIMETER
- Designed for the garage – the most powerful automotive multimeter offered by Fluke
- Functions and accuracy to solve problems on conventional and hybrid vehicles
- Pulse width function with millisecond resolution for fuel injector troubleshooting
- RPM measurements with optional inductive pickup
- Min/Max/Average recording with Min/Max Alert to capture variations automatically
- Peak Min/Max to record transients as fast as 250 µs
- Frequency measurement up to 200 kHz
- Standard multimeter functions: voltage, current, continuity, resistance
- Large digit display with dual-level bright backlight for readability in the garage
- Optional magnetic hanger for hands-free viewing
Description
Fluke 88V – Deluxe Automotive Multimeter
The Fluke 88V is the most powerful automotive multimeter in Fluke’s lineup. It combines automotive-specific functions such as millisecond pulse width for fuel injectors, RPM measurement (with optional pickup), and duty cycle, with the rugged accuracy Fluke is known for.
The meter handles voltages up to 1000 V AC/DC, current up to 10 A continuous (20 A for 30 seconds), frequency to 200 kHz, and includes temperature capability with an optional probe. With features like Peak Min/Max (250 µs), analog bar graph, Min/Max/Average recording, and Auto/Manual ranging, it’s built for demanding automotive diagnostics.
Its large dual-level backlit display improves visibility in garages, while the optional magnetic hanger provides convenience during hands-on work. Backed by a limited lifetime warranty, the 88V is designed for conventional and hybrid vehicle troubleshooting.
Manufacturer Specifications
| DC Voltage | |
|---|---|
| Maximum Voltage | 1000 V |
| Accuracy | ±(0.1% + 1) |
| Best Resolution | 0.01 mV |
| AC Voltage | |
| Maximum Voltage | 1000 V |
| Accuracy | ±(0.5% + 2) |
| AC Bandwidth | 5 kHz |
| Best Resolution | 0.01 mV |
| DC Current | |
| Maximum Amps | 10 A |
| Accuracy | ±(0.4% + 2) |
| Best Resolution | 0.001 mA |
| AC Current | |
| Maximum Amps | 10 A |
| Accuracy | ±(1.2% + 2) |
| Best Resolution | 0.001 mA |
| Resistance | |
| Maximum Resistance | 50 MΩ |
| Accuracy | ±(0.4% + 1) |
| Best Resolution | 0.1 Ω |
| Capacitance | |
| Maximum Capacitance | 9,999 µF |
| Accuracy | ±(1% + 2) |
| Best Resolution | 0.01 nF |
| Frequency | |
| Maximum Frequency | 200 kHz |
| Accuracy | ±(0.005% + 1) |
| Best Resolution | 0.01 Hz |
| Duty Cycle | |
| Maximum | 99.9% |
| Accuracy | ±(2%/kHz + 0.1%) |
| Best Resolution | 0.1% |
| Temperature | |
| Measurement Range | −200 °C to 1090 °C / −328 °F to 1994 °F (±1.0%, excl. probe) |
| Probe Range (80BK) | −40 °C to 260 °C / −40 °F to 500 °F (±2.2 °C or 2%) |
| Conductance | |
| Maximum | 60.00 nS |
| Accuracy | ±(1.0% + 10) |
| Resolution | 0.01 nS |
| Operating Range | |
| Operating Temperature | −20 °C to 55 °C |
| Storage Temperature | −40 °C to 60 °C |
| Physical | |
| Dimensions | 5.2 × 9.8 × 20.1 cm (2.06 × 3.86 × 7.93 in) |
| Weight | 624 g (22 oz) |
Tech Specs
| Multimeters Template | |
|---|---|
| Style | Hand-Held |
| Measures AC V | Yes |
| Measures DC V | Yes |
| Measures AC A | Yes |
| Measures DC A | Yes |
| True RMS | No |
| Maximum Voltage AC | 1000 V |
| Resolution AC Volts | 1 V (1000 mV) |
| Maximum Voltage DC | 1000 V |
| Resolution DC Volts | 1 V (1000 mV) |
| Maximum Current AC | 10 A |
| Minimum Current AC | 60.00 mA |
| Resolution AC Current | 0.01 mA |
| Maximum Current DC | 10 A |
| Minimum Current DC | 60.00 mA |
| Resolution DC Current | 0.01 mA |
| Basic Accuracy V DC | ±(0.1% + 1) |
| # Digit Display | 4.5 |
| Counts | 19999 |
| Backlight | Yes |
| Manual/Autoranging | Both |
| Resistance | Yes |
| Frequency | Yes |
| Capacitance | Yes |
| Temperature | Yes |
| Diode Testing | Yes |
| CAT Rating | CAT IV |
| CAT Voltage | 1000 V, 600 V |
| Peak Hold | Yes |
| Overload Protector | Yes |
| Data Hold | Yes |
| Low-Pass Filter | No |
| Duty Cycle % | 0.0 – 99.9% (±2%/kHz + 0.1%) |
Test Equipment General Attributes
| Unique Features | 0.1% DC accuracy. Current up to 10 A (20 A for 30s). Millisecond pulse width for fuel injectors. Min/Max/Avg with alerts. Peak Min/Max at 250 µs. Relative mode. Auto/Manual ranging. AutoHold™. Optional magnetic hanger for hands-free setup. |
|---|---|
| Additional Info | Large dual-level backlit display. Analog bar graph. Input Alert safety warning. Fast battery access door. Classic design with removable holster and probe storage. 10 MΩ input impedance won’t damage vehicle circuits. Limited lifetime warranty. |
| Safety Approval | CSA, UL |
| Interfaces I/O | Analog Input, Analog Output |
| Product Weight | 0.78 lbs |
| Product Height | 1.25 in |
| Product Length | 7.35 in |
| Product Width | 3.41 in |
| Data Logging | No |
| ECCN Number | 3A992 |
| Calibration Included | None |
| Battery Type | 9V |
| Power Supply Voltage | Battery Powered |
| Country of Origin | United States |
| UPC | 095969328906 |
